TENES

Tenes 3m
Tenes 3mhh
tenes 2
tenes dron 1

Standard equipment:

Optional equipment:

✔ welded hub,
✔ possibility to adjust the spacing between the discs:
960 mm – 1100 mm – 1240 mm,
✔ two disc rows of discs with rubber shock absorption,
✔ Ø 560 mm discs with maintenance-free hubs on
cone bearings,
✔ rear, tubular roller with bearing Ø 510mm or string
roller Ø 440mm,
✔ foldable, adjustable side discs,
✔ reinforced hitch with possibility of trailing on
category II and III hooks,

Optional equipment:

✔ screwed hub, disc Ø 560 mm
✔ screwed hub, disc Ø 610 mm
✔ side screens,
✔ floating side screens,
✔ hydraulic working depth
adjustment,
✔ route lights,
✔ automatic draw bar,
✔ optional rollers (table).

Model specifications:

Information about the rollers:


(m)


(HP/KM)
TENES 270 2,7 22 1340 100-120
TENES 300 3,0 24 1420 110-130
TENES 350 3,5 28 1700 130-150
TENES 400 4,0 32 1820 150-170

Information about the rollers:

Tenes
Rurowy/
Tubular 		Ø 510 mm ✔
Ø 600 mm ✔
Strunowy/
String 		Ø 440 mm ✔
Ø 520 mm ✔
Daszkowy/
V ring 		Ø 500 mm ✔
Ø 600 mm ✔
Daszkowy z profila/
V Ring bar 		Ø 500 mm ✔
Ø 600 mm ✔
Pierścieniowy/
Ring 		Ø 500 mm ✔
Ceownikowy/
Channel bar 		Ø 520 mm ✔
Ø 600 mm ✔
Teownikowy/
Tee-bar 		Ø 600 mm ✔
Packer Ø 510 mm ✔
Crosskill Ø 380 mm ✔
Ø 550 mm ✔
Dyskowy/
Disc 		Ø 600 mm ✔
Gumowy/
Rubber 		Ø 500 mm ✔
Spiralny/
Spiral 		Ø 500 mm ✔
Tandem daszkowy/
V ring tandem 		Ø 500 mm ✔
Ø 600 mm ✔
Tandem daszkowy z profila/
V Ring – bar tandem 		Ø 500 mm ✔
Ø 600 mm ✔
Tandem strunowy/
String tandem 		Ø 440 mm ✔
Tandem strunowo-rurowy/
String and pipe tandem 		Ø 440 mm
Ø 510 mm 		✔
Tandem ceownikowy/
Channel-bar tandem 		Ø 520 mm ✔
Tandem teownikowy/
Tee-bar tandem 		Ø 600 mm ✔
Tandem mulczujący/
Mulching tandem 		rura/pipe
Ø 140 mm 		✔
rura/pipe
Ø 270 mm 		✔
Tandem dyskowy/
Disc tandem 		Ø 600 mm ✔
Tandem pierścieniowy/
Ring tandem 		Ø 500 mm ✔
Tandem crosskill Ø 380 mm ✔
✔
STANDARD
✔
OPTION
